GCAN-4057 CANopen IO coupler
- Brand:
- GCAN
- Model:
- GCAN-4057
- Application:
- ● Industrial field network data monitoring; ● Remote communication for coal mines and oil wells; ● CAN teaching application remote communication; ● CAN industrial automation control system; ● CAN-bus application systems such as intelligent building control data broadcasting systems.
-
1. Equipment Introduction
The GCAN-4057 module from Shenyang Guangcheng Technology is an industrial-grade CANopen digital input/output module that integrates one standard CAN/CANopen interface, eight switch input channels, and eight switch output channels. By utilizing the GCAN-4057 module, users can collect digital input signals, output digital signals, control switches, and establish a connection between remote switch devices and the CANopen network, forming a control node for data signal collection and output within the CANopen network.
The GCAN-4057 module serves as a pivotal tool for digital signal acquisition and output, boasting compact size and convenient wiring. The module's bus interface integrates an isolation protection module, safeguarding it from potential damage caused by transient overvoltage and overcurrent. Its DIN rail mounting design facilitates seamless integration into various control cabinets.
2. Equipment Parameters
● CAN-bus supports CAN2.0A and CAN2.0B frame formats, conforming to ISO/DIS 11898 specifications;
● The CAN-bus communication baud rate is arbitrarily programmable between 10Kbps and 1Mbps;
● The CAN-bus interface employs electrical isolation, with an isolation module insulation voltage of 1500V DC;
● Powered by 9~30V DC, with a current of 140mA (quiescent current: 40mA);
● Number of digital input channels: 8 channels;
● Number of digital output channels: 8 channels;
● Digital input signal: Supports PNP and NPN types, switchable through the COM terminal;
● Digital input high-level signal (digital 1): +5V~30V;
● Digital input low-level signal (digital 0): ≤+3V;
● Digital output signal: PNP output, with a maximum of 500mA for a single channel; 350mA per channel for simultaneous output from 8 channels;
● DI, DO, and CANopen interfaces utilize terminal interfaces;
● Configure the module baud rate and node number using the dip switch;
● Electrostatic discharge immunity level: contact discharge ±4kV, air discharge ±8kV;
● Electrical Fast Transient/Burst Immunity Level: ±2kV for power interface and CAN interface; ±1kV for IO interface;
● Surge Immunity Level: ±1kV for Power Interface and IO Interface, ±4kV for CAN Interface;
● The available matching card rail connectors can be installed onto the DIN card rail;
● Operating temperature range: -40℃~+85℃;
3. Application Fields
● Industrial field network data monitoring;
● Remote communication for coal mines and oil wells;
● CAN teaching application remote communication;
● CAN industrial automation control system;
● CAN-bus application systems such as intelligent building control data broadcasting systems.
Welcome to inquire and learn more.
-
- ● CAN-bus supports CAN2.0A and CAN2.0B frame formats, conforming to ISO/DIS 11898 specifications;
● The CAN-bus communication baud rate is arbitrarily programmable between 10Kbps and 1Mbps;
● The CAN-bus interface employs electrical isolation, with an isolation module insulation voltage of 1500V DC;
● Powered by 9~30V DC, with a current of 140mA (quiescent current: 40mA);
● Number of digital input channels: 8 channels;
● Number of digital output channels: 8 channels;
● Digital input signal: Supports PNP and NPN types, switchable through the COM terminal;
● Digital input high-level signal (digital 1): +5V~30V;
● Digital input low-level signal (digital 0): ≤+3V;
● Digital output signal: PNP output, with a maximum of 500mA for a single channel; 350mA per channel for simultaneous output from 8 channels;
● DI, DO, and CANopen interfaces utilize terminal interfaces;
● Configure the module baud rate and node number using the dip switch;
● Electrostatic discharge immunity level: contact discharge ±4kV, air discharge ±8kV;
● Electrical Fast Transient/Burst Immunity Level: ±2kV for power interface and CAN interface; ±1kV for IO interface;
● Surge Immunity Level: ±1kV for Power Interface and IO Interface, ±4kV for CAN Interface;
● The available matching card rail connectors can be installed onto the DIN card rail;
● Operating temperature range: -40℃~+85℃;
- Packing
Standard package:Carton
Delivery Time
2~5 days after receipt of your payment by air express
After-sale service
GCAN provide one year free after-sales warranty,lifetime free software and technical support.
