GCAN-205 Modbus TCP to CAN converter
- Brand:
- GCAN
- Model:
- GCAN-205
- Application:
- ● Interconnection between industrial Ethernet devices and CAN network devices ● Electric power communication network ● Industrial Control Equipment ● High speed and large data communication ● Gateway bridge between CAN bus and serial bus; ● Industrial site network data monitoring; ● CAN teaching application remote communication; ● CAN industrial automation control system; ● Low speed CAN network data collection and analysis; ● Intelligent building control data broadcasting system and other CAN bus application systems. ● PLC equipment connected to CAN bus network communication;
-
1. Equipment Introduction
The Shenyang Guangcheng Technology GCAN-205 module is a protocol conversion module that integrates one standard Ethernet interface and one standard CAN interface from Modbus TCP to CAN. By using the GCAN-205 module, users can easily achieve interconnection and intercommunication between CAN bus network and Ethernet network, further expanding the scope of CAN bus network. GCAN-205 can bridge the Ethernet network with the CAN bus network. Users can integrate this intelligent protocol conversion module into their own system, enabling the Ethernet network and CAN bus, which do not have mutual communication capabilities, to quickly have communication capabilities. This saves development time, reduces development costs, and quickly seizes market opportunities.
The GCAN-205 module has been widely used in building network environments such as fieldbus laboratories, industrial control networks, and intelligent community monitoring. At the same time, the device has the characteristics of small size, plug and play, and the module uses a DIN rail installation method, making it particularly suitable for industrial sites or cabinets to be used in conjunction with other devices. The GCAN-205 module has integrated a CAN interface electrical isolation protection module, which prevents equipment damage caused by transient overcurrent/overvoltage and enhances the reliability of the system in harsh environments.
2. Equipment parameters
(1) Hardware features
● High speed 32-bit industrial grade controller;
● Embedded hardware watchdog timer;
● Use an external power supply (DC9-24V, 300mA) for power supply;
● Electrostatic discharge immunity level: Contact discharge ± 2kV, air discharge ± 15kV;
● Electrical fast transient pulse group immunity level: ± 1kV;
● Surge immunity level: ± 1kV;
● Working temperature range: -40 ℃~+85 ℃;
● Working humidity range: 5%~95% RH without condensation;
● Standard DIN rail installation method, specifically designed for industrial use.
(2) CAN attribute
● Integrate 1 CAN bus interface and use terminal wiring method;
● The CAN bus number includes: CAN_S, CAN_L, CAN_SND;
● The CAN bus supports CAN2.0A and CAN2.0B frame formats and complies with the ISO/DIS 11898 specification;
● The baud rate of CAN bus communication can be programmed between 5kbps and 1Mbps;
● The CAN bus interface adopts electrical isolation, and the insulation voltage of the isolation module is DC 1500V;
(3) Ethernet properties
● RJ45， Support 10/100M adaptive;
● Modbus slave support function codes: 03H, 04H, 06H, 16H;
● Support static or dynamic IP acquisition;
● Support heartbeat and timeout disconnect function;
● The work port is fixed, and both the target IP and target port can be set;
● Automatically restore connection resources after network disconnection and reliably establish TCP connections;
● Compatible with SOCKET working mode, the communication software of the upper computer follows the standard SOCKET rules.
3. Application Fields
● Interconnection between industrial Ethernet devices and CAN network devices
● Electric power communication network
● Industrial Control Equipment
● High speed and large data communication
● Gateway bridge between CAN bus and serial bus;
● Industrial site network data monitoring;
● CAN teaching application remote communication;
● CAN industrial automation control system;
● Low speed CAN network data collection and analysis;
● Intelligent building control data broadcasting system and other CAN bus application systems.
● PLC equipment connected to CAN bus network communication;
Welcome to inquire and learn more
-
- (1) Hardware features
● High speed 32-bit industrial grade controller;
● Embedded hardware watchdog timer;
● Use an external power supply (DC9-24V, 300mA) for power supply;
● Electrostatic discharge immunity level: Contact discharge ± 2kV, air discharge ± 15kV;
● Electrical fast transient pulse group immunity level: ± 1kV;
● Surge immunity level: ± 1kV;
● Working temperature range: -40 ℃~+85 ℃;
● Working humidity range: 5%~95% RH without condensation;
● Standard DIN rail installation method, specifically designed for industrial use.
(2) CAN attribute
● Integrate 1 CAN bus interface and use terminal wiring method;
● The CAN bus number includes: CAN_S, CAN_L, CAN_SND;
● The CAN bus supports CAN2.0A and CAN2.0B frame formats and complies with the ISO/DIS 11898 specification;
● The baud rate of CAN bus communication can be programmed between 5kbps and 1Mbps;
● The CAN bus interface adopts electrical isolation, and the insulation voltage of the isolation module is DC 1500V;
(3) Ethernet properties
● RJ45， Support 10/100M adaptive;
● Modbus slave support function codes: 03H, 04H, 06H, 16H;
● Support static or dynamic IP acquisition;
● Support heartbeat and timeout disconnect function;
● The work port is fixed, and both the target IP and target port can be set;
● Automatically restore connection resources after network disconnection and reliably establish TCP connections;
● Compatible with SOCKET working mode, the communication software of the upper computer follows the standard SOCKET rules.
- Packing
Standard package:Carton
Delivery Time
2~5 days after receipt of your payment by air express
After-sale service
GCAN provide one year free after-sales warranty,lifetime free software and technical support.
