GCAN-8311 Profinet converter
- Brand:
- GCAN
- Model:
- GCAN-8311
- Application:
- ● The main application areas of the GCAN-8311 combined Profinet slave gateway converter include: ● Connect with the distributed bus terminal module to form a complete control node; ● Perform data collection and transmit data using Profinet protocol.
-
1、 Equipment Introduction
GCAN-8311 is a high-performance Profinet slave/intelligent gateway independently developed by our company based on the Profinet bus. The equipment can be used as a Profinet slave station for Siemens 200SMART, 1200, 1500, 300 and other series PLCs; The device integrates 2 Profinet bus interfaces and 1 RS485 bus interface. GCAN-8311-XXX can serve as a gateway for the above-mentioned Siemens PLC, enabling communication between Siemens PLC and Modbus RTU master/slave stations through the "General Station Description Document (GSD)".
Note:
The corresponding sub model can only convert Siemens Profinet to one corresponding protocol, and the price varies depending on the protocol.
2、 Equipment parameters
● 2 Profinet bus interfaces (RJ45), supporting cascading from slave stations;
● Profinet bus transmission rate: 100Mbps;
● Profinet bus transmission distance (station to station distance): 100m (CAT5 cable);
● One 485 bus interface;
● The power supply adopts 24V DC (-15%/+20%);
● Electrical isolation is 1500 VDC;
● Working temperature range: -40 ℃~+85 ℃;
● Relative humidity: 10%~95%, no condensation;
● EMC：Zone B，IEC61131-2；
● IP rating: IP20
3、 Application Fields
● The main application areas of the GCAN-8311 combined Profinet slave gateway converter include:
● Connect with the distributed bus terminal module to form a complete control node;
● Perform data collection and transmit data using Profinet protocol.
Welcome to inquire and learn more.
-
- ● 2 Profinet bus interfaces (RJ45), supporting cascading from slave stations;
● Profinet bus transmission rate: 100Mbps;
● Profinet bus transmission distance (station to station distance): 100m (CAT5 cable);
● One 485 bus interface;
● The power supply adopts 24V DC (-15%/+20%);
● Electrical isolation is 1500 VDC;
● Working temperature range: -40 ℃~+85 ℃;
● Relative humidity: 10%~95%, no condensation;
● EMC：Zone B，IEC61131-2；
● IP rating: IP20
- Packing
Standard package:Carton
Delivery Time
2~5 days after receipt of your payment by air express
After-sale service
GCAN provide one year free after-sales warranty,lifetime free software and technical support.
