1.Equipment Introduction
GCAN-GT-413 is a programmable bus gateway/converter with IO. This device integrates 2 CAN bus interfaces, 1 Ethernet bus interface, 2 RS485 bus interfaces, and 1 RS232 bus interface. Before actual use, users need to write application programs for this device through OpenPCS software to achieve data conversion between different bus interfaces.
GCAN-GT-413 module supports multiple standard communication protocols, such as CANopen, SAE J1939, Modbus TCP, Modbus RTU, etc. Users can directly select the corresponding protocol function blocks to load and use them in actual use. The addition of function blocks makes the programming work of users simpler. Users only need to understand the basic PLC programming instructions and the characteristics and parameters of the corresponding bus protocols to complete the programming work.
GCAN-GT-413 module supports 12 digital DI inputs and 8 digital DO outputs.
GCAN-GT-413 can be programmed using OpenPCS software, which supports five standard PLC programming languages specified in the IEC-61131-3 standard, such as SFC (Sequential Function Chart), LD (Ladder Diagram), FBD (Function Block Diagram), ST (Structured Text), and IL (Instruction List). This makes the program highly portable and reusable. Moreover, the software also has multiple debugging functions (such as power-off, single-step, monitoring, etc.), making it more convenient to debug the program.
2. Equipment parameters
(1) High-speed 32-bit industrial-grade processor;
(2) Embedded hardware watchdog timer;
(3) Powered by external power supply (DC +24V, 100mA);
(4) Electrostatic discharge immunity level: contact discharge ±2KV, air discharge ±8KV;
(5) Electrical fast transient burst immunity level: ±1KV;
(6) Surge immunity level: ±1KV;
(7) Operating humidity range: 5% to 95% RH without condensation;
(8) 2 CAN bus interfaces, 1 Ethernet interface, 1 RS232 serial interface, 2 RS485 serial interfaces;
(9) Programming software: OpenPCS (conforming to IEC 61131-3 standard);
(10) Supports CANopen protocol master/slave functions;
(11) Supports Modbus RTU/TCP master/slave functions;
(12) Standard DIN rail mounting method, specially designed for industrial use.
(13) Electrical isolation of 1500 Vrms;
(14) Operating temperature range: -40°C to +85°C;
(15) Protection level: IP20.
3. Application Fields
(1) Data conversion between industrial Ethernet and CAN bus
(2) Interconnection of industrial Ethernet devices and CAN network devices
(3) Power communication networks
(4) Industrial control equipment
(5) High-speed, large data volume communication
(6) Distributed acquisition system for digital quantity acquisition
(7) Acquisition of switch quantities in industrial fields
(8) Output of digital quantity signals
