(81): CANopen stepper all-in-one machine
Many small and medium-sized multi axis equipment often encounter these pain points: traditional stepper system motors and drivers are arranged separately, the wiring inside the cabinet is complicated, and it occupies a large space; After increasing the number of axes in pulse control mode, the amount of wiring increases exponentially; Ordinary stepping is prone to losing steps and lacks real-time position feedback; The imported stepper scheme has a high cost and is not suitable for the transformation of economical multi axis projects.
The Shenyang Guangcheng GCAN-ISM-SP series CANopen stepper machine highly integrates the motor, driver, and encoder, follows the CiA402 standard CANopen protocol, and supports multiple motion modes such as position, speed, torque, and zeroing; Equipped with DI/DO limit and origin switches, it has multiple protections for overvoltage, overcurrent, stall, and position deviation; Working at a wide temperature range of -20 ℃ to+50 ℃, powered by DC low-voltage DC, with multi axis bus networking, and equipped with debugging software to complete parameter configuration, JOG jog and curve analysis.
Real implementation case: A small-scale labeling equipment project with multiple axes networked through CANopen bus, eliminating external drivers, simplifying cabinet wiring, real-time feedback of encoder position, solving the hidden danger of step loss, and shortening equipment debugging cycle.
Suitable for surface mount machines, textile equipment, AGV mechanisms, and small automated machines, with economical multi axis bus motion requirements. Welcome to add WeChat 13019325660 to obtain manuals, EDS files, and technical support.
