（33）：GCAN-4048
Industrial furnaces and heat treatment production lines commonly face difficulties in temperature measurement and collection: multiple furnace thermocouple points are scattered, one-to-one wiring cables are complex, and construction costs are high; Workshop frequency converters and high-power equipment generate strong electromagnetic interference, and weak signals from thermocouples are prone to drift and distortion; On site K/J/T/S multiple thermocouples are mixed, and conventional acquisition equipment is not compatible; The temperature difference between day and night is large, and ordinary collection equipment is prone to malfunction and shutdown under high and low temperature conditions.
Shenyang Guangcheng GCAN-4048 perfectly solves the above pain points, equipped with 8 independent thermocouple channels, four models can be configured separately, and the full-scale error is ≤ 0.1%; CAN channel 1500V electrical isolation, -40 ℃~+85 ℃ wide temperature stability, standard CANopen protocol, DIN rail compact and easy to install, supports SDO free setting of temperature measurement multiples and offsets.
Sharing a case study of a thermal treatment workshop: 10 annealing furnaces were renovated, and one GCAN-4048 was installed in each control cabinet to collect the temperature of K-type thermocouples in the furnace nearby. A single CAN bus was collected and sent to the central control PLC, reducing wiring by 70%. Temperature measurement in electromagnetic environment was carried out without deviation, and the furnace temperature curve was monitored in real time to prevent the occurrence of defective products.
The module is suitable for temperature measurement scenarios such as metallurgy, energy storage, oil wells, ovens, etc. There is a demand for distributed acquisition of multiple thermocouples. Welcome to call 13019325660.
Shenyang Guangcheng GCAN-4048 perfectly solves the above pain points, equipped with 8 independent thermocouple channels, four models can be configured separately, and the full-scale error is ≤ 0.1%; CAN channel 1500V electrical isolation, -40 ℃~+85 ℃ wide temperature stability, standard CANopen protocol, DIN rail compact and easy to install, supports SDO free setting of temperature measurement multiples and offsets.
Sharing a case study of a thermal treatment workshop: 10 annealing furnaces were renovated, and one GCAN-4048 was installed in each control cabinet to collect the temperature of K-type thermocouples in the furnace nearby. A single CAN bus was collected and sent to the central control PLC, reducing wiring by 70%. Temperature measurement in electromagnetic environment was carried out without deviation, and the furnace temperature curve was monitored in real time to prevent the occurrence of defective products.
The module is suitable for temperature measurement scenarios such as metallurgy, energy storage, oil wells, ovens, etc. There is a demand for distributed acquisition of multiple thermocouples. Welcome to call 13019325660.
